Features

- Power Supply: VDD=1.2V Typical

- VDDQ = 1.2V Typical

- VPP - 2.5V Typical

- VDDSPD=2.2V to 3.6V

- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals

- Low-power auto self refresh (LPASR)

- Data bus inversion (DBI) for data bus

- On-die VREFDQ generation and calibration

- Dual-rank

- On-board I2 serial presence-detect (SPD) EEPROM

- 16 internal banks; 4 groups of 4 banks each

- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)

- Selectable BC4 or BL8 on-the-fly (OTF)

- Fly-by topology

- Terminated control command and address bus

- PCB: Height 1.18" (30.00mm)

- RoHS Compliant and Halogen-Free

Specifications

CL(IDD)

17 cycles

Row Cycle Time (tRCmin)

45.75ns(min.)

Refresh to Active/Refresh Command Time (tRFCmin)

350ns(min.)

Row Active Time (tRASmin)

32ns(min.)

Maximum Operating Power

TBD W*

UL Rating

94 V - 0

Operating Temperature

0o C to +85o C

Storage Temperature

-55o C to +100o C

Three years Return To Base Warranty
